Latham Steel, based right here in Hamilton, is a name you can count on for reliable steel solutions. We take pride in supplying high-quality materials, including Carbon Steel tubing that meets the rigorous ASME SA 822 specification. Our team understands that your projects, from complex industrial systems to critical infrastructure, demand materials that perform consistently and safely. With a strong local presence and a deep commitment to quality, we provide not just the product but the knowledgeable support you need to ensure your work stands the test of time.
This Carbon Steel tubing, governed by the ASME SA 822 standard, is engineered for a dependable balance of strength and workability. Its specific chemical composition is carefully controlled to ensure reliable performance. This results in excellent mechanical properties, including good tensile strength and yield strength, allowing it to handle significant pressure and structural loads. The material’s inherent ductility also makes it suitable for various fabrication processes, meaning it can be bent or shaped as needed for your specific application without compromising its integrity.
| Product | ASTM A822 Seamless Steel Tubes |
| Specification | ASTM A822 / ASME SA822 |
| Standard | ASME SA822 is the standard applicable to Seamless cold drawn low carbon steel heat exchanger and condenser tubes |
| Size OD (In mm) | 3/4” (19.05mm), 1” (25.4mm), 1¼” (31.75mm), 1½” (38.1mm), 2” (50.8mm), 2½” (63.5mm), 3” (76.2mm) |
| Wall Thickness (BWG, mm) | 16BWG (1.651mm), 14BWG(2.108mm), 12BWG(2.769mm), 10BWG(3.404mm), 8BWG(4.191mm) |
| Application | For high, middle, low pressure boiler and pressure purposes |
| Length | 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; and so on. Max length: 27000mm, also U bending can be offered |
| Product Marking | ASTM A822 or ASME SA822, size, heat no., Lot No. and Manufacture name or logo. |
| Other Testing | Hydrostatic Test |
| Type | Seamless – Hot Rolled / Cold Drawn |
| Form | Round |
| International Standards | ASME, API, EN, DIN, ISO |
| End | Plain End, Beveled End, Coupling |
| Inspection | Third Party Inspection, Buyer Inspection |
| Packing | Weaving Bag, Seaworthy Bundles, Wooden Case if required |
| Specials | Sizes and Specification other than above can be manufactured on request |
| Certification | EN 10204 3.1 |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.18 | – | 0.27-0.63 | 0.048 | 0.058 | – | – | – | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel ASME SA 822 Tubing in Hamilton, New Zealand. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to reliable delivery and exceptional customer service, Jaxon Steel provides top-grade materials that ensure superior performance in various industrial applications. Trust us for all your Carbon Steel ASME SA 822 Tubing needs.
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 310 | – | 45 | 35 | ||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| – | EN P195TR2 Grade 10216-1 | – | ASTM A822 – | ASME SA 822 – | – |
You’ll find this versatile tubing at work in a wide range of essential applications, particularly where dependable pressure containment is key. It’s commonly specified for heat exchangers and condensers, where it efficiently transfers thermal energy in power plants and industrial facilities. It also serves as essential pressure piping, and is often the go-to choice for structural frameworks and mechanical components that require a robust and cost-effective material. Its reliability makes it a trusted solution for engineers and fabricators across numerous sectors.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
