Latham Steel, a reliable manufacturer and supplier based in Hamilton, New Zealand, provides robust and versatile IS 2062 E250 Sheets and Plates that cater to a variety of structural and engineering needs. These plates are crafted in line with IS 2062 standards, guaranteeing dependable strength, excellent weldability, and superb fabrication properties. The IS 2062 E250 material is a popular choice for medium-load construction projects, thanks to its reliability, consistency, and cost-effectiveness. Latham Steel upholds rigorous quality control, precise rolling, and a uniform chemical composition to deliver sheets and plates that are perfect for building structures, machinery fabrication, industrial frameworks, and general engineering tasks.
IS 2062 E250 Sheets and Plates are made up of carbon, manganese, silicon, sulfur, and phosphorus in carefully controlled proportions to ensure balanced strength and workability. With a minimum yield strength of around 250 MPa, they boast impressive tensile properties, stable ductility, and reliable toughness for moderate structural loads. Their fine-grain structure promotes good weldability, bending capability, and overall ease of fabrication. These mechanical characteristics enable E250 plates to consistently perform well across various engineering applications that demand reliable strength without the added complexity or expense of higher alloy or high-strength steels.
| Product Name | Fe 410WB Plates- IS 2062 E250 |
|---|---|
| Standard | IS 2062 |
| Equivalents | 43 D, St 44-3U, E28-4, S275J2G3 |
| Thickness | 6MM to 300MM |
| Width | 1500mm to 4050mm |
| Length | 3000mm to 15000mm |
| Certification | Mill Test Reports Available as per EN 10204 3.1 |
| Element | C.E. Value | Mn | C | S | Si | P | Nb+V+Ti |
| E-250 Gr-B | 0.41 max | 1.50 max | 0.22 max | 0.045 max | 0.40 max | 0.045 max | – |
| E-250 Gr-A | 0.42 max | 1.50 max | 0.23 max | 0.050 max | 0.40 max | 0.050 max | – |
| E-250 Gr-C | 0.39 max | 1.50 max | 0.20 max | 0.040 max | 0.40 max | 0.040 max | – |
| Grade | Tensile | Min Yield | Elongation | Thickness(mm) | Min Impact Energy | |
| Fe 410WB | 410Mpa | Min 250Mpa | 23% | ＜20mm | 27J | 0 |
| 410Mpa | Min 240Mpa | 23% | 20mm-40mm | 27J | 0 | |
| 410Mpa | Min 230Mpa | 23% | ＞40mm | 27J | 0 | |
| EN10025(93) | EN10025(90) | JIS3101 | BS4360 | DIN 17100 | NFA 35-501 |
| S275J2G3 | – | – | 43 D | St 44-3U | E28-4 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
IS 2062 E250 Sheets and Plates find extensive use in the construction, fabrication, automotive, and engineering sectors. Their adaptability makes them ideal for structural beams, platforms, frames, base plates, supports, tanks, ducts, railway components, and industrial equipment. They are also utilized in material-handling systems, agricultural machinery, transport vehicles, and general fabrication shops where reliable performance and straightforward processing are crucial. Thanks to their excellent weldability and formability, E250 plates are perfect for medium-duty applications, ensuring they meet the demands of various projects with ease.
