Latham Steel, based in Hamilton, New Zealand, has built a solid reputation as a reliable manufacturer and supplier of top-notch steel solutions for various industries in the region. One of their standout products is the 16Mo3 sheets and plates, which are highly sought after for applications that require resistance to high temperatures and pressures. With a strong emphasis on reliability, precision, and customer-focused service, Latham Steel carefully sources and fabricates materials that adhere to strict international standards. Their 16Mo3 offerings are specifically designed to thrive in challenging environments like power plants, refineries, and industrial boilers. Thanks to their advanced processing capabilities and unwavering commitment to excellence, Latham Steel plays a vital role in supporting New Zealand’s engineering and fabrication sectors.
When it comes to 16Mo3 sheets and plates, these low-alloy steel materials are primarily enhanced with molybdenum to boost their heat resistance and strength. The typical composition includes carbon (0.12–0.20%), along with manganese, silicon, phosphorus, sulfur, and about 0.25–0.35% molybdenum. This combination of elements results in impressive creep strength and better corrosion resistance at high temperatures. Mechanically, 16Mo3 showcases high tensile strength, remarkable toughness, and good weldability. Its yield strength usually falls between 220–275 MPa, while tensile strength ranges from 440–590 MPa, depending on the thickness. These characteristics make 16Mo3 an excellent choice for structural applications that face high pressure and temperature.
Standard :Â AISI, ASTM, BS, DIN, GB, JIS
Thickness : 3 – 300 mm
Width : 1000 – 4000 mm
Length :Â 1000 -12000 mm
| Grade | C | Si | Mn | P | S | Cr | Mo | Ni | N | Cu |
| 16 MO3 | 0.12/0.20 | 0.35 | 0.40/0.90 | 0.025 | 0.010 | 0.030 | 0.25/0.35 | 0.30 | 0.30 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 440-590 | 250 – 500 | 23 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
16Mo3 sheets and plates are a go-to choice in various industries that need dependable performance even in high temperature and pressure situations. You’ll often find them in boiler components, heat exchangers, steam generators, and pressure vessels at power generation plants. In the petrochemical and refinery fields, 16Mo3 is essential for furnace parts, reactor coils, and piping systems where thermal stability is a must. Its fantastic weldability and strength at high temperatures also make it a great fit for industrial fabrication, structural assemblies, and heavy-duty mechanical equipment. No matter if it’s in energy, processing, or manufacturing settings, 16Mo3 stands out for its durability and long-lasting performance in tough operating conditions.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
