From our base in Hamilton, we at Latham Steel take pride in supplying New Zealand’s marine industry with the exceptional quality of ABS DH36 shipbuilding steel. This isn’t just any steel; it’s a material specifically engineered to meet the rigorous demands of life at sea. We understand that the integrity of a vessel starts with its hull, which is why we ensure our DH36 sheets and plates offer the perfect combination of strength and resilience, providing shipbuilders with the reliable foundation they need for their most important projects.
The composition of this steel is carefully balanced with elements like carbon and manganese to achieve its renowned strength, while its mechanical properties are what truly set it apart. ABS DH36 is designed to deliver high yield and tensile strength, meaning it can withstand immense forces without deforming. Crucially, it also maintains excellent toughness at low temperatures, a vital characteristic for preventing brittle fracture in the cold waters often encountered by ocean-going vessels, ensuring long-term structural safety.
STANDARD:Â ASTM A131, ASME SA131
PLATES QUALITY: DH36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| Grade DH36 | C | Si | Mn | P | S | V | Al | Cr | Cu | Mo | Nb | Ni | Ti |
| 0.180 | 0.1-0.5 | 0.90-1.6 | 0.035 | 0.035 | 0.05-0.10 | 0.015 | 0.200 | 0.350 | 0.080 | 0.02-0.05 | 0.400 | 0.020 |
| Grade | Re | Rm | Elongation | Â |
|---|---|---|---|---|
| Â | Â | Â | A50mm | A200mm |
| Â | MPa | MPa | % | % |
| DH 36 | 355 | 490/620 | 22 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Latham Steel is one of the most prominent manufacturers and suppliers of superior quality ABS DH36 Shipbuilding Steel Sheet and Plates in Hamilton, New Zealand. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.Â
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| DH36 | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
When it comes to applications, ABS DH36 is the go-to choice for critical structural components in demanding marine environments. Its primary use is in the construction of ship hulls, decks, and other vital parts of commercial vessels, fishing boats, and offshore platforms. This steel’s proven ability to handle dynamic stresses and harsh saltwater conditions makes it indispensable for building structures where failure is not an option, providing peace of mind for designers, builders, and operators alike.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
