Based in the heart of Hamilton’s industrial sector, Latham Steel has built a strong reputation as a reliable partner for high-quality steel products. We are proud to supply API 5L Grade L290 pipe, a product engineered to meet the demanding requirements of the modern energy sector. Our commitment is to deliver materials that not only meet stringent international specifications but also provide the durability and performance our clients in New Zealand and beyond have come to trust for their most critical infrastructure projects.
The API 5L Grade L290 pipe is defined by a carefully balanced chemical composition and robust mechanical properties. It is a carbon manganese steel, often with micro-alloying elements, designed to offer a specified minimum yield strength of 290 MPa. This grade provides an excellent combination of high strength, good toughness, and reliable weldability, making it a versatile and dependable choice for constructing pipelines that must perform safely under substantial pressure over long periods.
| Specification | API 5L / ISO 3183 Hot Rolled . |
| API 5L Grade L290 Pipe Type | Seamless |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter Size | 3/8″ NB To 30″ NB (Nominal Bore Size) |
| Wall Thickness | Schedule 20 To Schedule XXS (Heavier On Request) Up to 250 mm Thickness |
| Length | 5 To 7 Meters, 09 To 13 Meters, Single Random Length, Double Random Length And Customize Size. |
| Pipe Ends | Plain Ends / Beveled Ends / Coupling |
| Surface Coating | Epoxy Coating / Colour Paint Coating / 3LPE Coating. |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.28 | – | max 1.30 | 0.03 | 0.03 | – | – | – | – | Nb+Ti+V max 0.15 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 415 | – | 60 | – | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Latham Steel is a top manufacturer and supplier of high-quality API 5L Grade L290 Pipe ​​​​​​​​​​​​​​​​​ products in Hamilton, New Zealand. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
This specific grade of pipe is essential for constructing pipelines that transport oil and natural gas from source to refinery, forming the backbone of the energy distribution network. Beyond the energy sector, its strength and reliability make it suitable for a variety of high-pressure applications, including transporting other fluids and gases in industrial settings and even for major structural purposes like piling. When you need a material that ensures the integrity and safety of a pressurized system, L290 pipe is a tried-and-true solution.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
