Latham Steel, a trusted manufacturer and supplier located in Hamilton, New Zealand, specializes in high-quality SAE 1045 Steel Sheets and Plates. These products are crafted for medium-strength, high-wear mechanical and industrial applications. Renowned for their excellent machinability, toughness, and precise dimensions, Latham Steel guarantees that its SAE 1045 offerings adhere to rigorous international standards. This medium-carbon steel grade is a popular choice for parts that need enhanced hardness and strength compared to low-carbon steels. With dependable supply, precise processing, and strict quality control, Latham Steel plays a vital role in supporting New Zealand’s engineering, fabrication, automotive, and machinery sectors with durable and cost-effective SAE 1045 steel solutions.
SAE 1045 Steel Sheets and Plates are composed of about 0.43–0.50% carbon, along with manganese, phosphorus, sulfur, and small amounts of silicon. This medium-carbon makeup gives them significantly greater strength and hardness than low-carbon steels while still allowing for good machinability. Their mechanical properties include high tensile and yield strength, excellent wear resistance, and improved toughness. SAE 1045 responds well to heat treatment methods like quenching and tempering, which enhance hardness and fatigue resistance. It maintains stable mechanical performance even under moderate to heavy loads, making it ideal for demanding mechanical components.
| Specification | ASTM A830 AISI 1045, SAE 1045, |
| Grade | SAE J403 Grade 1045 |
| Condition | hot rolled or normalized |
| Width | Â 200 to 2000mm |
| Thickness | Â 6 to 800mm |
| Length | 2000 to 6000mm |
| Heat treated method | By flame or induction |
| MN | FE | S | C | P |
|---|---|---|---|---|
| 0.60 – 0.90% | 98.51 – 98.98% | ≤ 0.050% | 0.420 – 0.50% | ≤ 0.040% |
| MECHANICAL PROPERTIES | Â | Â |
|---|---|---|
| Â | Metric | Imperial |
| Tensile Strength, Ultimate | 565 MPa | 81,900 PSI |
| Tensile Strength, Yield | 310 MPa | 45,000 PSI |
| Modulus of Elasticity | 200 GPa | 29,000 KSI |
| Hardness, Brinell | 163 | 163 |
| Elongation at Break (in 50 mm) | 16.0% | 16.0% |
| Bulk Modulus (Typical for Steel) | 140 GPa | 20,300 KSI |
| Poissons Ratio | 0.290 | 0.290 |
| Shear Modulus | 80 GPa | 11,600 KSI |
| Grade | EU EN | DIN,WNr | JIS | AFNOR | BS | GOST | ISO | UNS |
| 1045 | C45E (1.1191) | Ck45 | S45C | XC45 XC48H1 | 080M46 CFS8 | 45 | C45E4 | G10450 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Length x Width | Thickness |
|---|---|
| mm | mm |
| 2000 x 1000 | 0.8 |
| 2440 x 1220 | 1.0 |
| 2500 x 1250 | 0.9 |
| 2500 x 1250 | 0.8 |
| 2000 x 1000 | 1.20 |
| 2000 x 1000 | 1.0 |
| 2000 x 1000 | 0.9 |
| 1830 x 1220 | 1.0 |
| 2500 x 1250 | 1.20 |
| Thickness | Length x Width | Mass per Sq m |
|---|---|---|
| mm | mm | Kg/m2 |
| 30.00 | 2000 x 1000 | 235.50 |
| 30.00 | 4000 x 2000 | 235.50 |
| 30.00 | 2500 x 1250 | 235.50 |
| 30.00 | 5000 x 2500 | 235.50 |
| 30.00 | 3000 x 1500 | 235.50 |
| 30.00 | 5000 x 1250 | 235.50 |
| 40.00 | 2000 x 1000 | 314.00 |
| 32.00 | 2000 x 1000 | 251.20 |
| 30.00 | 10000 x 2500 | 235.50 |
| 30.00 | 6000 x 2500 | 235.50 |
| 32.00 | 2500 x 1250 | 251.20 |
| 32.00 | 3000 x 1500 | 251.20 |
| 32.00 | 5000 x 2500 | 251.20 |
| 32.00 | 4000 x 2000 | 251.20 |
| 35.00 | 3000 x 1500 | 274.75 |
| 35.00 | 4000 x 2000 | 274.75 |
| 35.00 | 2500 x 1250 | 274.75 |
| 40.00 | 2500 x 1250 | 314.00 |
| 40.00 | 3000 x 1500 | 314.00 |
| 40.00 | 4000 x 2000 | 314.00 |
SAE 1045 Steel Sheets and Plates find extensive use in the manufacturing of mechanical parts, industrial components, and equipment that require higher strength and wear resistance. Typical applications include gears, shafts, axles, pins, bolts, crankshafts, sprockets, couplings, and structural machine parts. They are also utilized in agricultural machinery, automotive components, hydraulic systems, tooling plates, and medium-duty load-bearing structures. The material’s heat-treatable nature makes it perfect for parts that need to withstand tough conditions.
