For over four decades, Latham Steel has been a trusted name in Hamilton, New Zealand, recognized for its reliable manufacturing and supply of high-grade materials. Our specialty lies in Alloy Steel T1 Tubing, a product born from a deep understanding of local industry needs. We take pride in delivering tubing solutions that offer exceptional performance for demanding applications, ensuring our clients receive material that not only meets but exceeds expectations, backed by our hands-on expertise and commitment to quality.
The strength of Alloy Steel T1 lies in its carefully balanced composition, primarily chromium and molybdenum, which gives it an excellent combination of high tensile strength and commendable toughness. This material is further characterized by its strong creep resistance, meaning it can withstand significant stress under high temperatures without deforming. This unique set of properties makes it a remarkably durable and reliable choice, capable of performing consistently in environments where other materials might fail.
Alloy Steel T1 Seamless Tubes Specifications |
||
| Specifications | : | ASTM A/ASME SA213, A691 |
| Dimensions | : | ASTM, ASME and API |
| Tubes Size | : | 1 / 2” OD up to 5” OD, customs diameters also available |
| Outer Diameter | : | 6-2500mm; WT:1-200mm |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / EFW / Fabricated |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
|
Grade |
C≤ |
Mn |
P≤ |
S≤ |
Si≤ |
Mo |
|---|---|---|---|---|---|---|
|
T1 |
0.10~0.20 |
0.30~0.80 |
0.025 |
0.025 |
0.10~0.50 |
0.44~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| T1 | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T1 Tubing in Hamilton, New Zealand. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T1 Tubing needs!
This unique combination of properties makes Alloy Steel T1 Tubing ideal for critical, high-stress environments. You’ll commonly find it in power generation systems, particularly in boiler tubes and superheater components that handle high-pressure steam. It’s also extensively used in high-temperature piping for refineries and chemical processing plants. Beyond these sectors, its proven durability makes it a solid choice for structural applications in engineering and construction projects where long-term reliability under pressure is an absolute necessity.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
