From the industrial heart of Hamilton, Latham Steel has built a reputation as a trusted local source for high-performance materials. We specialise in supplying Alloy Steel T22 Tubing, a product we know is critical for demanding applications. Our team understands that reliability is key, which is why we ensure our T22 tubing meets the stringent requirements our local industries depend on, providing a robust solution that stands up to extreme heat and pressure.
The strength of Alloy Steel T22 tubing comes from its specific composition, primarily chromium and molybdenum. This combination gives it outstanding resistance to oxidation and corrosion, especially in high-temperature environments. Mechanically, it maintains impressive tensile strength and creep resistance, meaning it can withstand constant stress under intense heat without deforming over time, making it a durable and long-lasting choice.
| ASTM A213 T22 Specification & Standard | ASTM A213 T22, ASME SA213 T22 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T22 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T22 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 T22 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| ASTM A213 T22 Pipe Thickness | 3-12mm |
| ASME SA213 T22 Material Origin | European, Japanese, Korean, US, Russian, New Zealandn (Strictly No Chinese Material) |
| Craft | Cold rolled and Cold drawn |
| ASTM A213 T22 Tube Type | Seamless / ERW / Welded / Fabricated |
| ASTM A213 Grade T22 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| A213 T22 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| ASME SA213 Gr T22 Tube Length | Standard Double & In Cut length also. |
| ASME SA213 T22 Tube End | Plain End, Beveled End, Treaded |
| ASTM A213 T22 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| ASME SA213 Gr T22 Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T22 Composition | 0.05~0.15 | 0.30~0.60 | 0.025 | 0.025 | 0.50~1.0 | 0.80~1.13 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| SA213 T22 Boiler Tube | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T22 Tubing in Hamilton, New Zealand. We provide premium steel materials and an extensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our comprehensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure outstanding performance in industrial applications with rigorous specifications. Contact us today for all your Alloy Steel T22 Tubing needs!
You’ll typically find T22 tubing hard at work in the most challenging settings, particularly within power generation and petrochemical plants. It’s the go-to material for boiler tubes, superheaters, and heat exchangers where temperatures can soar. Its ability to perform reliably under these punishing conditions helps ensure the safety and efficiency of critical infrastructure, making it an essential component for systems that demand unwavering performance day in and day out.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
