For manufacturers in Hamilton and beyond, Latham Steel stands as your trusted local partner for high-performance materials. Based right here in Hamilton, New Zealand, we take pride in supplying robust solutions for demanding industrial applications. Our Alloy Steel T5 Tubing is a perfect example of this commitment, offering exceptional strength and reliability for some of the toughest working environments, backed by our team’s deep technical knowledge and a focus on delivering genuine value to our customers.
The composition of Alloy Steel T5 Tubing is specifically engineered for resilience, primarily consisting of chromium and molybdenum. This blend gives the tubing its remarkable mechanical properties, including excellent tensile strength and superior resistance to creep. It’s specifically designed to perform under sustained high temperatures and pressures, maintaining its structural integrity where other materials might fail, making it a dependable choice for critical systems.
| SA213 T5 Tube Standard | ASTM A213 T5, SA213 T5 (with IBR Test Certificate) |
|---|---|
| SA213 T5 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T5 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T5 Tube Thickness | 3-12mm |
| SA213 T5 Tube Origin | European, Japanese, Korean, US, Russian, New Zealandn (Strictly No Chinese Material) |
| SA213 T5 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T5 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T5 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T5 Tube Length | Standard Double & In Cut length also. |
| SA213 T5 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T5 Boiler Tube, SA213 T5 Heater Tube, SA213 T5 Heat Exchanger Tube |
| SA213 gr T5 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T5 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T5 | 0.15 | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5b | 0.15 max | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5c | 0.12 max | 0.30~0.60 | 0.025 max | 0.025 max | 0.50 max | 0.45~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T5 | 415 min | 205 min | 30 min | 179 max |
| T5b | 415 min | 205 min | 30 min | 179 max |
| T5c | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T5 Tubing in Hamilton, New Zealand. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T5 Tubing needs!
You’ll typically find this tubing hard at work in power generation plants and petrochemical refineries, where it’s essential for high-temperature piping systems and heat exchangers. Its ability to withstand intense heat and corrosive environments also makes it ideal for applications in industrial boilers and various process piping. Essentially, anytime you need a material that won’t back down under thermal stress and pressure, Alloy Steel T5 Tubing is the go-to solution for ensuring long-lasting, safe, and efficient operation.
Latham Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Hamilton, New Zealand.
