Located in the heart of Hamilton’s industrial landscape, Latham Steel has built a strong reputation as a reliable manufacturer and supplier of high-quality steel products. We take particular pride in our expertise with ASTM A500 tubing, a cornerstone of modern structural design. Our commitment to local industry means we provide Hamilton and the wider New Zealand market with dependable, ready-access to this essential material, supporting everything from major commercial builds to innovative local projects with robust, homegrown steel solutions.
Our ASTM A500 tubing is a cold-formed welded carbon steel tube, primarily composed of steel with carefully controlled levels of carbon, manganese, and other elements to ensure consistent performance. This specific composition gives the tubing its excellent mechanical properties, including high strength and good ductility. It’s these characteristics—like its formidable yield and tensile strength—that make it a preferred choice for structural supports, capable of handling significant loads while maintaining its integrity.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Composition, % | ||||
| Element | Grades A, B and D | Grace C | ||
| Heat Analysis | Product Analysis | Heat Analysis | Product Analysis | |
| Carbon, max | 0.26 | 0.30 | 0.23 | 0.27 |
| Manganese, max | … | … | 1.35 | 1.40 |
| Phosphorus, max | 0.035 | 0.045 | 0.035 | 0.045 |
| Sulfur, max | 0.035 | 0.045 | 0.035 | 0.045 |
| Copper, when copper steel is specified, min | 0.20 | 0.18 | 0.20 | 0.18 |
| Yield Strength, min | 170 MPa |
| Ultimate Strength, min | 310 MPa |
| Elongation in 50 mm, min | 35% |
| Hardness (Rockwell B), max | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1½ (38.1) and under | 0.050 | 1.39 | |
| Over 1½ to 2½ (38.1 to 63.5),incl | 0.062 | 1.72 | |
| Over 2½ to 4 (63.5 to 101.6), incl | 0.075 | 2.09 | |
| Over 4 to 6 (101.6 to 152.4), incl | 0.087 | 2.42 | |
| Over 6 to 8 (152.4 to 203.2), incl | 0.100 | 2.78 | |
| Over 8 (203) | 0.112 | 3.11 | |
The versatility of this tubing is truly remarkable, making it a common sight in our built environment. You’ll find it forming the sturdy skeletons of commercial buildings, shopping centres, and agricultural sheds, providing the essential framework that holds everything up. Beyond large structures, it’s also widely used for constructing industrial racks, handrails, and a variety of supportive frames in machinery. Its clean, rectangular or round profiles are not only strong but also allow for neat, architecturally pleasing designs, proving that practical strength and good aesthetics can go hand-in-hand.
