From the heart of Hamilton, New Zealand, Latham Steel proudly stands as a trusted manufacturer and supplier, bringing quality and reliability directly to the local and international market. Our specialisation in materials like Carbon Steel A423 GR 1 Tubing reflects our commitment to meeting the precise demands of modern industry. We understand that behind every specification is a critical project, and our role is to provide the foundational components that ensure strength, safety, and longevity for the work you do.
When it comes to its makeup, Carbon Steel A423 GR 1 features a carefully balanced composition, primarily iron with a low alloy content that includes key elements like nickel for enhanced performance. This specific recipe grants the tubing excellent mechanical properties, offering a remarkable combination of high tensile strength and good ductility. It’s this inherent toughness that allows it to perform reliably under pressure and withstand challenging operating conditions, making it a dependable choice for demanding applications.
| Size Range | : | ½” OD to 16” OD |
| Standards | : | AASTM A 423 / ASME SA 423 |
| Grade | : | ASTM A423 GR 1 / ASME SA423 GR 1 |
| Type | : | Round, Square, Rectangle, Hydraulic, Honed Tubes |
| Length | : | Single Random, Double Random & Customize Size |
| Type | : | Weathering Steel |
| End | : | Plain End, Beveled End, Threaded End |
| Element | C, % | Mn, % | P, % | S, % | Si, % | Cu, % | Cr, % | Ni, % |
|---|---|---|---|---|---|---|---|---|
| A/SA 423 GR 1 | 0.15 max. | 0.55 max. | 0.06–0.16 | 0.060 max. | 0.10 min. | 0.20–0.60 | 0.24–1.31 | 0.20–0.70 |
| Grade | Yield Strength MPa(min) | Tensile Strength MPa | Elongation % (min) |
| Corten A | 355 | 470-630 | 20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel A423 GR 1 Tubing in Hamilton, New Zealand. We offer premium steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A423 GR 1 Tubing needs!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
This particular grade of tubing truly shines in applications where reliability is non-negotiable. You’ll commonly find it serving as the backbone in heat exchangers, condenser systems, and various pressure vessels, especially where lower temperatures are a factor. Its consistent performance makes it a go-to material for critical infrastructure within power generation facilities and chemical processing plants, proving its worth by ensuring the safe and efficient transfer of fluids and gases day in and day out.
