For over a decade, Latham Steel has been a cornerstone of Hamilton’s industrial landscape, building a reputation for precision and dependability. We take pride in our role as a dedicated New Zealand manufacturer and supplier, providing high-quality materials to a diverse range of local industries. Our Carbon Steel A192 Tubing exemplifies this commitment, offering a robust and reliable solution engineered for demanding high-pressure environments, right from the heart of the Waikato.
The composition of A192 carbon steel tubing is carefully balanced for performance, primarily consisting of iron with a controlled carbon content. This specific blend is designed to ensure excellent thermal conductivity, which is crucial for its primary function. The material meets strict standards for tensile strength and yield strength, providing the mechanical integrity needed to withstand significant internal pressure and high temperatures without compromising its structural form.
| Craft | Cold rolled and Cold drawn |
| Standards | ASTM, ASME and API |
| Length | Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Thickness | 3-12mm |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type | Seamless / ERW / Welded / Fabricated |
| Tolerance | Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Form | Round, Hydraulic Etc |
| Origin | European, Japanese, Korean, US, Russian, New Zealandn (Strictly No Chinese Material) |
| End | Plain End, Beveled End, Treaded |
| Specialized in | Large Diameter ASTM A192 Pipe |
| Size | 1/2” NB to 36” NB |
|
C, % |
Mn, % |
Si, % |
P, % |
S, % |
|
0.06-0.18 |
0.27-0.63 |
0.25 max |
0.035 max |
0.035 max |
|
Tensile Strength , MPa |
Yield Strength , MPa |
Elongation, % |
Hardness, HB, WT≥5.1mm |
Hardness, HRB, WT＜5.1mm |
|
325 min |
180 min |
35 min |
137 max |
77 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel A192 Tubing in Hamilton, New Zealand. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A192 Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
A192 tubing is essential in the construction of heat exchangers, boilers, and superheater systems where efficient heat transfer under pressure is non-negotiable. You’ll find it at work in power generation facilities, large-scale industrial processing plants, and various marine applications. Its reliability makes it the go-to choice for engineers who need a proven material to safely contain heated water, oil, or steam, ensuring critical systems operate smoothly and safely day in and day out.
